Q647H-16C 氣動法蘭固定球直通流道硬密封鑄鋼（WCB）球閥

概述

固定球閥的球體，采用上、下兩根閥桿固定，工作時，流體壓力不會使球體向閥座移動，閥座不會承受過大壓力而變形。閥桿部份設有自潤滑軸承，減少磨擦，開關扭距小，兩閥座均采用彈簧設預緊。密封采用聚氟乙烯鑲?cè)脘撊?nèi)，鋼圈后部設有彈簧，保證閥座緊貼球體。當閥門中腔壓力異常升高超過彈簧頂緊力，閥座后退脫離球體，達到自動泄壓效果，壓后閥座自動復位。結構的先進性使固定球閥的密封性能穩定操作省力，使用壽命長，極適用于長輸管線和一般管線。

Summary

The sphere of Q47 type standing ball valve is fixed with upper and lower valve stems. When it works, for fluid pressure is unable to make sphere move towards valve base, the valve base won't be deformed for enduring over pressure.  There is self-lubricating bearing seton the part of valve stem to reduce friction, and its switch-torque is small. Both valve bases are pertensioned  by setting spring. Referring to sealing, adopt the way to inset polytetrafluoroethylene into steel-ring  with a spring on  its  rear end, which can ensure valve base cling to sphere. When the cavity pressure in valve transnormally excesses spring tension, valve base will back off and separate from sphere to get the effect of automatic pressure release.The valve base will automatically reset after being pressed.  Thanks to advanced structure, the standing ball valve has stable sealing performance, labor-saved operation and long using life. It is es-pecially applicable for long conveymg pipeline and general pipeline.

全通徑設計

按照客戶的要求可以提供全通徑

或縮徑閥門，全通徑閥門具有與管子

內徑完全一致的通道直徑，減少渦流

便于清掃管道。

Full bore design

According to the customer's

demand,the fullbore orthe redu-

ced bore can be provided. The f-

ull bore valve has the diameter of

channel completely equalto the

 in ner diameter of pipe to facilitat-

e to clean the pipe.

阻塞與排泄功能

固定球閥采用彈簧預緊，閥座密

封為雙活塞．利用話塞原理密封．上

下游側的閥座使流體阻斷．閥體中腔

裝放空閥排空，閥底裝有排污閥排污，

Block & Bleed Function

 Fixed ball valve adopts spri-

ng to pretighten.And seat sealis

double pistons.lt adopts piston p-

rinciple to seaI.Upstr-Eam and d-

ownstream seats make fluid stop.

And the emptying valve installed

on the middle cavity is used to e-

mpty and the blowdown valve in-

stalled at the bottom of valve to c-

lear off dirt to facili-tate to clean

the pipe.

防火結構

萬一發生火災或異常升溫使PT

FE軟化燒損時，閥座支承圈防火密封

面可以和球體接觸．起到密封作用且

符合AP1607和AP16FA

Fire-proof structure

When the fire happens orthe

temperatue unusually rises to m-

ake PTFE soften to damage.the

fireproof sealsurface of seat su-

pported circle can contact with b-

all to have seal function.This co-

nforms to therequirements of A-

Pl 607 and AP16FA.

防靜電設計

采用鉻鎳不銹鋼的彈簧和小球使

球體、閥桿和閥體之間相互導電，從

而把靜電完全釋放。

Anti-static design

Chrome and nickelstainless-

teel spring and small ball are ad-

opted to make electroconductive

among ball. Stem and body to co-

mpletely releasestatic.

設計、制造標準

1、設計、制造按GB/T12237-89

2、連接法蘭JB/T 79-94

3、閥門檢查和試驗按GB/T13927-89

Standard for design and manufacture

1、DesignManafacfure According to GB/T 12237-89

2、FlangeDimensionAccording tojBfT 79-94

3、valve Check and Test According to GB/T 13927-89

公稱壓力Nominal    PN(MPa)pressura

產 品 型 號Product Type

主要零件材料

Parts

Material

閥體

Body

WCB

ZG1Cr18Ni9Ti

CF8

CF3

ZG1Cr18Ni-

12Mo2Ti

CF8M

CF3M

球體、閥桿

Ball,Stem

2Cr13

1Cr18Ni9Ti

0Cr19Ni9-

（304）

00Cr19Ni11-

（304L）

1Cr18Ni12-

Mo2Ti

0Cr17Ni12-

Mo（316）

00Cr19Ni14-

Mo2（316L）

閥座

Seat

四氟乙烯、對位聚苯

適用工況

Applicable

Condrtion

適用介質

Applicable mediumt

水、蒸汽、油品等

Water，Steam，Oil

硝酸等腐蝕性介質

Netricalid Corrosive

強氧化性介質

Oxgen medium

醋酸等腐蝕性介質

Acetil acid coirosive medium

尿素等腐蝕性介質

Urea corrosive medium

工作溫度（℃）

Working

Temperatdre

-29~150(四氟乙烯)    -28~300(對位聚葳)

試驗壓力

（MPa）

Test pressure

殼體

Shell

1.5培

密封（液）

Sesl（liquid）

1.1培

密封（氣）

Sesl（gas）

0.6MPa

蝸輪傳動  Turbine

在手動型號的Q后插“3”表示，示例：Q347F-16C Represeting by“3”inserted befere manual“Q”

氣動    Pheumatic

在手動型號的Q后插“6”表示，示例：Q647F-16C Represetingby“6”inserted befere manual“Q”

電動    Electric

在手動型號的Q后插“9”表示．示例：Q947F-16C Represeting by“9”inserted befere manual“Q”

附注    Remark

選用縮徑球閥，在公禰通徑數值后加S表示，示例：DN100S

Selecting reduce Bore,insert“S”affer figure of DN.
